JUKI FEEDER REEL HOOK 16 ASM E46117060A0B

JUKI FEEDER REEL HOOK 16 ASM E46117060A0B

JUKI FEEDER REEL HOOK 16 ASM E46117060A0B

101 401-82186 BANK CABLE (9_10-EB1 CN7) ASM

102 401-82187 BANK CABLE (11_12-EB1 CN8) ASM

103 401-82188 BANK CABLE (13_14-EB1 CN9) ASM

104 401-82189 BANK CABLE (15_16-EB1 CN10) ASM

105 401-82190 BANK CABLE (17_18-EB1 CN11) ASM

106 401-82191 BANK CABLE (19_20-EB1 CN12) ASM

107 401-82192 BANK CABLE (21_22-EB1 CN13) ASM

108 401-82193 BANK CABLE (23_24-EB1 CN14) ASM

109 401-82194 BANK CABLE (25_26-EB1 CN15) ASM

110 401-82195 BANK CABLE (27_28-EB1 CN16) ASM

111 401-82196 BANK CABLE (29_30-EB1 CN17) ASM

63.SYSTEM DIAGRAM (3)

1 401-28871 IO CONTROL PCB ASM

2 401-29323 IO-R BKR SERIAL CABLE ASM

3 401-28872 SAFETY PCB ASM

4 401-82246 R BKR-SF CABLE ASM

5 401-82245 SF-YR TOP SENSOR RELAY CABLE ASM

6 401-65028 XY LMT SENSOR ASM

7 400-02254 COVER OPEN SW CABLE ASM

8 401-46405 COVER LOCK SV ASM

9 401-29010 MINI SIGNAL TOWER CABLE ASM(OP)

10 401-82268 MTS I/F CABLE ASM

11 401-84212 MTS I/F CABLE2 ASM

12 401-29336 MTS I/F BR CABLE ASM

13 401-28875 CONVEYOR PCB ASM

14 EZ-1755690-11 RELAY POWER (RJ1S-CLD-D24)

15 EZ-1755691-11 SOCKET RELAY (SJ1S-05B)

16 401-83536 POWER SUPPLY UNIT B ASM

17 #01 401-87824 POWER SUPPLY UNIT B ASM_EN

18 EZ-1755690-11 RELAY POWER (RJ1S-CLD-D24)

19 EZ-1755691-11 SOCKET RELAY (SJ1S-05B)

20 401-28876 E BANK RELAY PCB ASM
